Supporting 433MHz With high gain of 11dBi Good durable performance
|
Electrical Specification |
|
|
Model No. |
MNTBOPA433G11 |
|
Frequency Range |
433MHz |
|
Gain |
11dBi |
|
Horizontal Beamwidth |
65±5º |
|
Vertical Beamwidth |
|
|
F/B Ratio |
≥15dB |
|
VSWR |
≤1.5 |
|
Impedance |
50Ω |
|
Polarization |
Vertical |
|
Max.Power |
50W |
|
Connector |
N-female |
|
Lightning Protection |
DC Ground |
|
Mechanical Specification |
|
|
Dimension |
1000x500x200mm |
|
Weight |
11kg |
|
Rated Wind Velocity |
36.9m/s |
|
Reflector material |
Aluminum |
|
Operational Humidity |
< 95％ |
|
Radome Color |
Grey |
|
Radome material |
Fiberglass |
|
Operating temperature |
-40～55 ℃ |
|
Suitable pole diameter |
￠40～￠110mm |
