Supporting 698~2700MHz With high gain of 5dBi Good durable performance
|
Electrical Specification |
|
|
Model No. |
MNTOOA5 |
|
Frequency Range |
698-960/1710-2700MHz |
|
Gain |
5±0.5dBi |
|
Horizontal Beamwidth |
360 º |
|
Vertical Beamwidth |
65±15/40±8º |
|
VSWR |
≤1.6 |
|
Ovality |
≤±2dB |
|
Impedance |
50Ω |
|
Polarization |
Vertical |
|
Max.Power |
50W |
|
Connector |
N-female |
|
Lightning Protection |
DC Ground |
|
Mechanical Specification |
|
|
Dimension |
190*65*65mm |
|
Weight |
0.25kg |
|
Rated Wind Velocity |
36.9m/s |
|
Reflector material |
Aluminum |
|
Operational Humidity |
< 95％ |
|
Radome Color |
White |
|
Radome material |
ABS |
|
|
|
