Supporting 2G/3G/4G together Good durable performance Working with all weather conditions
|
Electrical Specification |
|
|
Model No. |
MNTOFA682701 |
|
Frequency Range |
680~960/1710~2700MHz |
|
Gain |
2.5dBi |
|
Horizontal Beamwidth |
360º |
|
Vertical Beamwidth |
70±3º |
|
Ovality |
≤2dB |
|
VSWR |
≤2 |
|
Impedance |
50Ω |
|
Polarization |
Vertical |
|
Max.Power |
50W |
|
Connector |
N-Female |
|
Lightning protection |
DC Ground |
|
Mechanical Specification |
|
|
Dimension |
¢32x350mm |
|
Weight |
0.3Kg |
|
Rated Wind Velocity |
36.9m/s |
|
Operational humidity |
< 95％ |
|
Radome color |
White |
|
Operating temperature |
- 40～55℃ |
