With gain of 5dBi With magnetic base Working with all weather conditions Good durable performance
|
Electrical Specification |
|
|
Model |
MNTTA2401 |
|
Frequency Range |
2400~2500MHz |
|
Gain |
5±0.5dBi |
|
Horizontal Beamwidth |
360 º |
|
Vertical Beamwidth |
60±15º |
|
VSWR |
≤2.0 |
|
Impedance |
50Ω |
|
Polarization |
Vertical |
|
Max.Power |
50W |
|
Connector |
SMA-Male(with 3m cable) |
|
Mechanical Specification |
|
|
Dimension |
¢48*200mm |
|
Weight |
0.025kg |
|
material |
Copper |
|
Radome Color |
Black |
|
Radome material |
ABS |
|
Operating temperature |
-40～55º |
