Supporting 3G system With high gain of 10dBi Good durable performance Working with all weather condition
|
Electrical Specification |
|
|
Model No. |
MNTOFA192110 |
|
Frequency Range |
1920~2170MHz |
|
Gain |
10dBi |
|
Horizontal Beamwidth |
360º |
|
Vertical Beamwidth |
20±3º |
|
Ovality |
≤2dB |
|
VSWR |
≦1.5 |
|
Impedance |
50Ω |
|
Polarization |
Vertical |
|
Max.Power |
50W |
|
Connector |
N-Female |
|
Lightning protection |
DC Ground |
|
Mechanical Specification |
|
|
Dimension |
¢20x850mm |
|
Weight |
0.5Kg |
|
Rated Wind Velocity |
36.9m/s |
|
Operational humidity |
< 95％ |
|
Radome color |
Grey |
|
Operating temperature |
- 40～55℃ |
